| Model Number | TP-040503GB-01 |
| Printhead | SG1024 |
| Number of Printheads | 3 |
| Print Speed |
70 pieces/hour (black , 1200*1200DPI, 11"*11" print size)
54 pieces/hour (black, 1200*1200DPI, 34.6*40.8 print size)
|
| Ink Type | Pigment ink |
| Color |
K C M Y W |
| Work Environment |
Temperature: 15℃-28℃;Relative Humidity: 40%-60% |
| Rolling System |
Automatic |
| Print Interface |
USB3.O/ Network Interface |
| RIP Software |
CADlink |
| Power Supply | AC220V ± 10%.50/60 ± 1Hz |
| Power (Watt) | 2500W |
| Language Of Operating System | Chinese & English |
| Printer Size | L1800mm*W1480mm*H1280mm |
| Net Weight |
202kg |
 |
01 Epson I3200 Printhead
Original Print Heads High density and long life.
|
 |
02 Two-in-One Printing and Laminating
Realize prints laminated on one machine, greatly improve printing efficiency and smaller size.
|
 |
03 Aluminum Alloy Cap Station
Provide better moisturizing effect and protection to the print head.
|
 |
04 Print Head Wipers
Not easy to scrape the print heads, long motor life, and improve efficiency.
|
 |
05 Silent Rail
Japan THK double rail design, is more stable and durable.
|
 |
06 Bilateral collision avoidance
Stop in time when encountering an obstacle to protecting the printhead.
|
 |
07 UV lamp adjustment and UV lamp water cooling system
Fabric printing of various thicknesses can be realized by lifting the platen, multi-purpose.
|
 |
 |
 |
 |
 |
 |
